PLPE90-064 Gearbox for Fagor FKM21.45 Servo Motor

The PLPE90-064-SSSA3AE-Z14/30/80/100/B5/M6 is a precision planetary gearbox engineered for high-performance motion control applications. It offers a 64:1 reduction ratio across two stages, ensuring high torque output and precise positioning. The gearbox features a 19 mm input bore, making it compatible with the Fagor FKM21.45 servo motor.​

📏 Key Specifications

• Gearbox Model: PLPE90-064-SSSA3AE-Z14/30/80/100/B5/M6

• Gearbox Type: Planetary

• Frame Size: 90 mm

• Reduction Ratio: 64:1 (2-stage)

• Input Bore Diameter: 19 mm

• Output Shaft Diameter: 14 mm

• Mounting Interface: B5 Flange

• Lubrication: Lifetime lubrication

• Backlash: ≤ 8 arcmin

• Efficiency: ≥ 95%

• Operating Temperature Range: -25°C to +90°C
