Eaton FAZD63/3 63A 3 Pole Miniature Circuit Breaker D Curve 15kA UL1077

Eaton FAZD63/3 Supplementary Protector Miniature Circuit Breaker. Rated at 63 Amps with a 15 kA interrupting capacity, this 3-pole D-curve breaker is designed for applications with high inrush currents, including motors, transformers, and industrial machinery.

Built to UL 1077 standards, the FAZD63/3 provides dependable supplemental circuit protection for industrial control panels and automation equipment.

Features

• Manufacturer: Eaton
• Model: FAZD63/3
• Current Rating: 63 Amps
• Number of Poles: 3
• Circuit Breaker Type: Supplementary Protector
• UL Standard: UL 1077
• Trip Curve: D Curve
• Interrupt Rating: 15 kAIC
• Frequency: 50/60 Hz
• Voltage Rating: Up to 480 VAC (application dependent)
• Standard Screw Terminals
• DIN Rail Mountable
• Designed for High Inrush Current Applications (10–20 × In)

Applications

• Industrial Control Panels
• CNC Machinery
• Manufacturing Equipment
• Motor Protection
• Automation Systems
• Conveyor Systems
• Transformers
• OEM Electrical Equipment

Package Includes

• (1) Eaton FAZD63/3 63A 3-Pole Circuit Breaker
