Freedom12
Heavy-Duty CNC Performance for Large-Format Production
The Freedom 12 CNC Router by Diversified Machine Systems (DMS) is a high-performance, large-format solution engineered for industrial operations that require speed, precision, and serious cutting power. With a generous 5’ x 12’ aluminum table, 12″ of Z-axis travel, and a powerful Hiteco ATC spindle, this 3-axis moving gantry machine is optimized for high-volume nested-based manufacturing, custom cabinetry, and composite panel processing.
Equipped with an automatic tool changer, drill bank, pneumatic pop-up pins, and a dust collection-ready hood, the Freedom 12 is built to streamline your workflow and reduce setup time—making it a standout choice for shops processing large sheets of wood, aluminum, plastic, and composites at scale.
Support & Warranty
• 3-axis industrial CNC router with moving gantry design
• Fagor 8070 OL controller with 17” LCD screen
• Ball screw drive and laser-calibrated X/Y axes
• 5’x12’ machined aluminum table with steel threaded inserts
• Hiteco PowerTech 300 ATC spindle (10.5 HP S1 / 12.5 HP S6)
• 10-position automatic tool change rack
• 5+4 drill bank (1.7kW, 6,000 RPM) on fixed plate
• Pneumatic pop-up pins for easy material referencing
• HSK-63F 10-piece tooling package included
• Dust collection hood supports 5” line
• Optional Becker vacuum pump (5, 10, or 15 HP)
• Ethernet, USB & Serial connectivity
• Cutting Area: 48” x 48”
• Z-Axis Travel: 12” with 9” clearance under bridge
• Rapid Feed Rate: Up to 1,400 IPM
• Calibration: Laser-calibrated X & Y axes
• Spindle Rotation: M04 M-code for reverse operation
• Power Requirements: 220V, 3-phase, 60 Hz (Amps depend on spindle)
• Lubrication: Manual system
• Table Material: 1” phenolic (optional aluminum upgrade)
Wood, Foam, Composites, Aluminum, Plastics, Acrylics, Leather
Woodworking, Orthotics, Automotive, Plastics & Acrylics, Sign Making, Aerospace, Medical, Marine, Energy, Manufacturing
Compare Freedom Machines
48″
48″
12″
C Axis Optional
48″
96″
12″
C Axis Optional
60″
120″
12″
C Axis Optional
60″
144″
12″
C Axis Optional
8kW
24000
4.5-8kW
Hiteco MT200, MT201, PT300, PT400
13kW/ 15kW
24000
4.5-13kW
Hiteco MT200, MT201, PT300, PT400
8kW
24000
4.5-8kw
Hiteco MT200, MT201, PT300, PT402
8kW
24000
8kW
Hiteco PT300, PT400
Spinning Ball Nut & Recirculating Ball Screw
4’x4′
Rack-Man
Fagor + Fagor
10
Spinning Ball Nut & Recirculating Ball Screw
4’x8′
Rack-Man
Fagor + Fagor
10
Spinning Ball Nut & Recirculating Ball Screw
5’x10′
Rack-Man
Fagor + Fagor
12
Rack & Pinion
5’x12′
Rack-Man
Fagor + Fagor
12
